BBS-XP

Heavy Duty Mulcher

Features & Specs

  • Powerful, Reliable 350 HP Cummins Tier-III Turbo Diesel
  • Efficiently Mulches, Harvests, and Bales all in ONE Step, with ONE Operator and ONE Machine
  • Low-profile Fully Enclosed Forward-tilt Cab
  • Pressurized Cab w/ Comfortable Suspension Seat
  • Best in Class, Patented “Sabre Tooth” Cutting Technology – Pulverizes Wood into Sawdust
  • Hydrostatic Drive/Steer System with Single Joystick Controller
  • Rear View Camera
  • Hydraulic Cutter Head Guide Bar Extends to Assist Felling Trees
  • Front Halogen Exterior Lights
  • Super Low Ground Pressure Captive Track, or Aggressice & Rugged Steel Track Options





With the BBS-XP Bio-Energy Baling System,  you will cut more wood in less time than with any competitor in its class. With both Captive Track and Rugged Steel Track options, PRODUCTIVITY,  PERFORMANCE & PROFITABILITY will become the hallmarks of your business. Call for a demonstration today, and experience Gyro-Trac’s Performance Promise with BBS-XP Bio-Energy Baling Sytem.

MACHINE DIMENSIONS

Overall Length: 300 in (762 cm)
Overall Width: 102¼ in ( 260 cm)
Overall Height: 115 in (292 cm)
Operating Weight: 30,000 lbs (13,607 Kg)
Ground Pressure: 4.7 psi (32.4 kPa)
Ground Clearance: 14½ in (37 cm)

ENGINE SPECIFICATIONS

Make: Cummins in-line 6-cylinder, 4-stroke diesel
Model: QSL9
Horsepower: 350 hp @ 2200 RPM
Torque: 911 ft LBS (1235 N m) @ 2000 RPM
Cooling System: Ethylene Glycol/Water
Cooling Capacity: 5.5 US gal. (21 liters)
Operating Temp: 185°F (85°C) - 214°F
Pressure: 16 psi (110 kPa atmosphere)

FUEL SYSTEM

Capacity: 97 US gal. (367 liters)

HYDRAULIC DRIVE SYSTEM (CLOSED LOOP)

Hydraulic Tank: 60 US gal. (227 liters)
Traction:
- Dual Traction Motors
Rotor:
- Dual Rotor Motors
Baler/Chipper:
- Baler
- Chipper
Radiator Fan Drive Motor:
- Rated Pressure: 4000 psi (27579 kPa)

FUEL TANK

Capacity: 97 US gal. (367 liters)

GEAR BOX

Ratio: 1.52:1

TRACK SYSTEM

Belts: 6-Ply Rubber
Cross Links: (78 per track): 28 in. (71 cm) Heat Treated
Belt Tensioner: Greased Filled 4000 psi (27579 kPa)

CAB

Steel Construction
- ROPS: ISO 8082 & CSA B352.0
- FOPS: ISO 8083 & G608:
- OPS: ISO 8084
Hydraulic Tilt Mechanism: Electric Hydraulic Pump
Windows: Lexan MR-10
Seat: Adjustable Suspension w/Armrest & Seat Belt
HVAC: 3-Speed, Positive Pressure

TOMA-AX 700HFBBS CUTTER-HEAD

Maximum rpm: 2350 rpm
Number of Teeth: 30 Fixed
Dual Rotor Motors
Dual Rotor Pumps
Operating Pressure: 4000 psi (27579 kPa)

Gyro-Trac’s SABRE-TOOTH TITAN cutting technology - PULVERIZES Wood into Sawdust-like Mulch.

The new SABRE-TOOTH design is the NEXT GENERATION of "disruptive technology," improving on Gyro-Trac's Planar tooth.

  • It begins with a WIDER TOOTH, held in place with a WEDGED FRICTION BLOCK, taking all the force off of the single bolt. THAT'S RIGHT! Only one bolt to quickly and easily replace worn teeth.
  • The CONTROLLED BITE is now achieved with TWO instead of one control rib under the tooth.
  • The distance between control ribs is wider.
  • The KNOCK-OUT RELIEF that reduces resistance by allowing the wood chip to curl into the relief, now has a SPLIT BLOCK strategically placed to SPLIT THE CHIP and further REDUCE the size of the wood chip.
  • This new design creates a SELF-CLEANING effect, clearing the tooth for the next bite.

Along with a perfectly tuned hydraulic recipe, you can now understand how Gyro-Trac machines can mulch more wood with Less Weight, Less Energy and Less Fuel than any of our competitors. You can also understand how the smallest mulch in the business leaves behind that famous, Gyro-Trac "Park-Like effect," and the fine, rapidly biodegradable mulch just simply Won’t Wick Fire, making a Gyro-Trac the perfect machine for cutting fire breaks.
